Turntable System

Turntable conveyors are compact directional systems used at points where product flow needs to change direction by 90° or 180°. They enable controlled directioning of different load formats such as packaged products, crates, boxes, and pallets without disturbing their position on the line. Designed to operate at low speeds, these systems offer a practical solution for line breaking and direction changing needs in confined spaces.

Flow Management and Line Features

Turntable conveyors, with their mechanical structure that keeps the product fixed in the center during rotation, help prevent alignment loss. Thanks to PLC-controlled speed and positioning features, products are transferred in the correct direction in a controlled manner after rotation. Roller, modular belt, or non-slip surface options support flow stability according to the type of product being transported.

90° and 180° direction change capability

Controlled and stable transport at low speed

Compatible structure with packaged products, boxes and pallets

Compact design suitable for narrow spaces

PLC controlled position and speed management

Roller, modular belt or coated surface options

Centering design that maintains product alignment

Applications

Turntable conveyors are used in production and logistics processes where direction change is required

Packaging and shrink lines

Box and crate transport lines

Pallet transport and palletizing systems

E-commerce and logistics centers

Chemical, cleaning and cosmetic product lines

Integrated Systems

Turntable conveyors can be configured to work together with different transport modules in the production line

Flat belt conveyors

Roller conveyors

Spiral conveyors

Merging / Sorting conveyors

Accumulation conveyors

Palletizing and storage automation systems

Direction control modules after knife-edge transfer

Technical Specifications

Feature Description
Direction Change 90° / 180°
Surface Type Roller, modular belt or non-slip plate
Body Stainless steel (AISI 304 / 316) or carbon steel
Drive Structure Motor-reducer or non-driven (gravity assisted)
Load Capacity Light - heavy load options
Control PLC-based position and speed control
Speed Low speed, controlled rotation
Cleaning Easy-access structure, maintenance-friendly design

Provide directional control on the line

Turntable conveyor solutions safely guide product flow in confined spaces, simplify line layout, and make directional changes controllable.
